Cordierite Ceramic Support Disc

Product Features and Brief Description Cordierite support discs for positioning and separating parts in heating assemblies. Specify the support points, slots, clearances and retention method on the drawing.

Inquire Now
shx@norkeceramics.com

Product Description
Application
Packaging and Logistics

Product Description Cordierite support discs provide a shaped interface for locating or separating parts within an assembly. The key design question is where the disc carries load and where it must leave clearance. Show these areas on the drawing so a support feature is not mistaken for a sliding or free-clearance feature. Specify the support and retention features Include the outside profile, thickness, bore and any grooves, notches or holes. If the disc supports wire, tube or another component, show its cross-section and the required seating position. State whether the disc is held by a shaft, a housing shoulder, fasteners or an external fixture. Check interfaces as a set Identify contact faces and the direction of load. Show the clearances required around moving or expanding parts. Mark alignment features and the datum used to inspect their position. Describe the working temperature, cycling and surrounding atmosphere. For replacement parts, a photograph of wear or fracture can help explain the installation, but the quotation still needs agreed geometry and acceptance requirements. Send the assembly context with your enquiry Provide the support disc drawing, mating-part details and quantity. If the disc routes a heating element, the heating disc page lists additional element-layout information. Contact NORKE to review your support-disc requirements.
Application Profile: disc dimensions, bore, grooves, notches and fixing features. Interfaces: supported part dimensions, contact faces, load direction and clearances. Review: installation method, temperature cycle and agreed inspection features.
Packaging and Logistics Note any thin sections or projecting features that require separation from adjacent parts. Agree packing quantities and identification for different disc variants.
